Quickship

Hadrian, Inc.

Threaded top hinge pin for Hadrian Baked enamel partition door

SKU:: HAD-631400
MFG Part #:: 631400

Description

DESCRIPTION

Replacement hinge pin for Hadrian Partition baked enamel door. Intended for use as bathroom partition hardware.

Material
Head and upper threaded portion	: steel
Lower portion	: White nylon
Head
Thickness	: 7/64" (between 3/32" and 1/8")
Dia	: 1/2"
Drive	: #25 Torx tampruf
Threaded portion
Dia	: 7/16"
Height	: 5/16"
Nylon portion
Dia	: 3/8"
Length	: 1
Other door items by Hadrian that work with this product	:
- TP H12 upper hinge
- TP H8 Lower hinge
- TP H1 Male cam assembly
- TP H2 Female cam
- TP H5 Inner knob
- TP H4 ADA Inner knob
- TP H9 Outer knob
- TP 140 Strike/keeper
- TP 7810 Bumper hook
Tools	:
16IN1TOOL with Torx tampruf bit sizes T10H, T15H, T20H & T25H.
The TP H3 hinge pin takes the T25H.
